Ferromatik MV200-970
Product information "Ferromatik MV200-970"
Manufacturer: Ferromatik, Type: MV200-970, 2001, Condition: running production, Operating hours: approx. 80,000, Clamping force: 200t, Screw diameter: 50 mm, Injection weight in polystyrene: 405 g, Stroke volume: 471 cm³, Injection pressure: 2,058 bar
Payment: 100% prior to delivery
Payment: 100% prior to delivery
| 01-manufacturer: | Ferromatik |
|---|---|
| 02-type: | MV200-970 |
| 03-year of construction: | 2001 |
| 04-condition: | aus laufender Produktion |
| 05-operating hours: | ca. 80.000 |
| 10-CLAMPING UNIT: | - |
| 11-clamping force: | 200 t |
| 12-opening path: | 750 mm |
| 13-mould installation height min: | 300 mm |
| 14-mould installation height max.: | - |
| 15-tie bar distance (h x v): | 560 x 560 mm |
| 16-plate dimension (h x v): | 840 x 822 mm |
| 17-centering (fix- movingplate): | 160 / 160 mm |
| 20-INJECTION UNIT: | IU970 |
| 21-screw diameter: | 50 mm |
| 22-injection weight in polystyrol: | 405 g |
| 23-stroke volume: | 471 cm³ |
| 24-injection pressure: | 2.058 bar |
| 30-CONTROL: | IQT44 |
| 31-screen language: | DE |
| 32-operating manuel: | DE |
| 40-EQUIPMENT: | - |
| 41-core pulls: | 2 |
| 42-air valves: | - |
| 43-hot runner control devices : | - |
| 44-robot interface: | Euromap 12 |
| 50-GENERAL DATA: | - |
| 51-installed heating capacity: | 18,8 kW |
| 52-pump drive power: | 37,0 kW |
| 53-total installed power: | Motor + Heizung |
| 54-total weight: | 9.000 kg |
| 55-total size L x B x H: | 5,5 x 1,9 x 2,4 m |
